제품사양
| 항목 | 사양 |
|---|---|
| Communication type | Real - Time Express (Panasonic distributed network specification) |
| Communication port | RJ45 |
| Physical layer | 100Base-TX Full Duplex (by IEEE 802.3u) |
| Transmission speed | 100 Mbps |
| Transmission cycle time | 0.5 ms (data update: 1ms or 0.5ms) |
| Transmission bytes | 16 byte |
| Control Axis | 16 Axes BASE, Max. 32 Axes (Option contact board) |
| Max. install board of system | 8 boards (Max. 256 nodes) |
| LED display | Power(Yellow), Link(Green), Error(Red), Communication(Green) |
| Number of configuration nodes | Max. 32 nodes |
| Network connection | RJ45 RX/TX, Standard STP cable (above CAT5e) Min. 0.6m (between nodes, Max. 200m(total) |
| Bus interface | PCI 2.2 , Memory Access |
| Connector | Comm. RJ45 LAN X 2EA |
| Power supply / Current consumption | DC 5V/ 1.5A |
| Operating temperature / Humidity | Temperature 0 ~ 55 °C/ Humidity 5~90% (No condensation) |
| Storage temperature | -20 ~ 70°C |
| Weight | 120g |
| Exterior dimension of product | 174.63 (W) mm x 106 (L) mm |
